Calumet_County_2021_Orthophoto (ImageServer)

View In: ArcGIS JavaScript ArcGIS Online Map Viewer ArcGIS Earth

Service Description: Ayres Associates provided Calumet County with digital, 4-band orthoimagery services in 2021 as part of WROC. The aerial imagery was collected on April 2nd and 3rd using a Leica Geosystems ADS100 sensor mounted in a fixed-wing aircraft. Aerial imagery was collected to support 0.5 foot ground sample distance (GSD) orthoimagery to meet ASPRS Class II horizontal accuracy specifications at 1" = 100' map scale. The 6-inch pixel orthoimagery was produced to meet or exceed a horizontal accuracy of 1.4 feet RMSE according to ASPRS Positional Accuracy Standards for Digital Geospatial Data. Resultant orthoimagery was rectified to a DEM created from existing QL2 LiDAR acquired in 2018. Orthoimagery was delivered in PLSS section GeoTiff and MrSID tiles and a project-wide MrSID mosaic. Supplemental Information: The Wisconsin Regional Orthoimagery Consortium (WROC) is a multi-entity group of county members and partners led by regional planning commissions (RPCs) and WROC representatives from Ayres Associates. The goal of the consortium is to build and sustain a multi-participant program to acquire digital orthoimagery and elevation data throughout Wisconsin. Orthoimagery was collected for Calumet County in 2021 to provide consistent deliverable products and accuracy standards for each of the participating entities.

Name: Calumet_County_2021_Orthophoto

Description: Ayres Associates provided Calumet County with digital, 4-band orthoimagery services in 2021 as part of WROC. The aerial imagery was collected on April 2nd and 3rd using a Leica Geosystems ADS100 sensor mounted in a fixed-wing aircraft. Aerial imagery was collected to support 0.5 foot ground sample distance (GSD) orthoimagery to meet ASPRS Class II horizontal accuracy specifications at 1" = 100' map scale. The 6-inch pixel orthoimagery was produced to meet or exceed a horizontal accuracy of 1.4 feet RMSE according to ASPRS Positional Accuracy Standards for Digital Geospatial Data. Resultant orthoimagery was rectified to a DEM created from existing QL2 LiDAR acquired in 2018. Orthoimagery was delivered in PLSS section GeoTiff and MrSID tiles and a project-wide MrSID mosaic. Supplemental Information: The Wisconsin Regional Orthoimagery Consortium (WROC) is a multi-entity group of county members and partners led by regional planning commissions (RPCs) and WROC representatives from Ayres Associates. The goal of the consortium is to build and sustain a multi-participant program to acquire digital orthoimagery and elevation data throughout Wisconsin. Orthoimagery was collected for Calumet County in 2021 to provide consistent deliverable products and accuracy standards for each of the participating entities.

Single Fused Map Cache: true

Tile Info:

Height: 256
Width: 256
DPI: 96
Levels of Detail: 11
- Level ID: 0 [ Start Tile, End Tile ]
- Level ID: 1 [ Start Tile, End Tile ]
- Level ID: 2 [ Start Tile, End Tile ]
- Level ID: 3 [ Start Tile, End Tile ]
- Level ID: 4 [ Start Tile, End Tile ]
- Level ID: 5 [ Start Tile, End Tile ]
- Level ID: 6 [ Start Tile, End Tile ]
- Level ID: 7 [ Start Tile, End Tile ]
- Level ID: 8 [ Start Tile, End Tile ]
- Level ID: 9 [ Start Tile, End Tile ]
- Level ID: 10 [ Start Tile, End Tile ]
Format: MIXED
Compression Quality: 75.0
LERC Error: NaN
Origin: X: -1.76461E7
Y: 1.7292199999999993E7
Spatial Reference: 0 (0) LatestVCSWkid(0)

Storage Info:

Storage Format: esriMapCacheStorageModeCompactV2
Packet Size: 128

Extent:

Initial Extent:

Full Extent:

Pixel Size X: 0.5

Pixel Size Y: 0.5

Band Count: 5

Pixel Type: U8

RasterFunction Infos: {"rasterFunctionInfos": [{ "name": "None", "description": "", "help": "" }]}

Mensuration Capabilities: Basic

Inspection Capabilities:

Has Histograms: true

Has Colormap: false

Has Multi Dimensions : false

Rendering Rule:

Min Scale: 250000

Max Scale: 250

Min LOD: 0

Max LOD: 10

Copyright Text: Calumet County Wisconsin Land Information Office, Ayres and Associates

Service Data Type: esriImageServiceDataTypeGeneric

Min Values: 0, 0, 0, 0, 0

Max Values: 199, 187, 172, 201, 255

Mean Values: 84.242121212121, 75.345454545455, 61.459393939394, 92.971515151515, 185.15242424242

Standard Deviation Values: 55.494224501981, 50.019620943574, 42.526959573214, 60.372754547426, 111.28743609913

Object ID Field:

Fields: None

Default Mosaic Method: Center

Allowed Mosaic Methods:

SortField:

SortValue: null

Mosaic Operator: First

Default Compression Quality: 75

Default Resampling Method: Bilinear

Max Record Count: null

Max Image Height: 4100

Max Image Width: 15000

Max Download Image Count: null

Max Mosaic Image Count: null

Allow Raster Function: true

Allow Copy: true

Allow Analysis: true

Allow Compute TiePoints: false

Supports Statistics: false

Supports Advanced Queries: false

Use StandardizedQueries: true

Raster Type Infos:

Has Raster Attribute Table: false

Edit Fields Info: null

Ownership Based AccessControl For Rasters: null

Child Resources: Info Histograms Statistics Key Properties Legend Raster Function Infos

Supported Operations: Export Image Identify Measure Compute Histograms Compute Statistics Histograms Get Samples Compute Class Statistics Query Boundary Compute Pixel Location Compute Angles Validate Project
